750 SERIES

CONVEYOR SYSTEMS

Overview

Specification



TREPKO have developed and produced conveyor systems over a period of several decades. This experience is demonstrated by the TRAD slat belt system which fulfits a wide range of functions in the food, technochemical and pharmaceutical industries.


Performance

The Conveyor is suited to light weight product and operates vertically, horizontally or diagonally, with variable speed according to the application. The system is designed for high efficiency and durability, coupled with minimal maintenance, marking it ideal for tough environments, and allows ready accessability. Conveyor system is supplied in modules, consisting of drive units, straights, curves, elevations, legs and guide rails resulting in a very adaptable system.

Benefits

  • possibility of vertical, horizontal or diagonal transport
  • variable speed according to the application
  • wide range of functions in the ford, techno-chemical and pharmaceutical industries
  • high efficiency
  • easy maintenance
  • adjust to different production conditions
  • system consisting of drive units, straights, curves, elevations, legs and quide rails
  • length of the conveyor is determined by product weight and the number of curves

Technical data

Conveyor lenghtdetermined by product weight and the number of curves
Product
– width range
– max. weight
– total product weight per conveyor

25-300 mm
20 kg
150 kg
Speedvariable ok. 2-45 m/min.
Temperaturefrom -20°C to +60°C during continuous operation, up to +100°C temporarily

Watch the video and learn more about       750 Series

Do you need more information?

Contact us: info@trepko.com

Check our 760 Series

We also encourage you to familiarize yourself with the specification of pick & place packaging machines.
